Stainless Steel Pumps

Pump Type

SS Monoblock Pumps

Pump Model No: SSM-0.25

● Pump Type – Centrifugal, Vertical, Coupled type, Self Priming Pump,
● Pump Material – Casing, Impeller and Back Plate is Made of PP (Polypropylene) Material
● Shaft – SS 316 / Titanium
● Pump Leanth – 400 mm
● Max Head – Upto 9 Meters
● Max Flow – 85 Leter per Minute
● Inlet & Outlet – 25 mm x 25 mm (Threaded end Connection)
● Motor Specification – 0.5 HP, NFLP, 2800 RPM, 50 Hz, 3 Phase, Hindustan Make.
● Fluid Temprature – 70° C (Max)
● Seal Type – Sealless
● Impeller – Open Type

Pump Model No: SSM-0.5

● Pump Type – Centrifugal, Horizontal, Monoblock type, Non Self Priming Pump,
● Pump Material – Casing, Impeller and Back Plate is Made of SS (Stainless Steel 316)
● Shaft – SS 316
● Max Head – Upto 16 Meter
● Max Flow – 120 Leter per Minute
● Standard Duty – 6.5 m3/hr @ 10 Meter
● Inlet & Outlet – 25 mm x 25 mm (Threaded and Flange end Connection)
● Motor Specification – 0.5 HP, NFPL, 2800 RPM, 50 Hz, 1 Phase.
● Fluid Temprature – 90° C (Max)
● Seal Type – Single Spring with Ceramic v/s Carbon Facings
● Impeller – Closed Type

Pump Model No: SSM-1

● Pump Type – Centrifugal, Horizontal, Monoblock type, Non Self Priming Pump,
● Pump Material – Casing, Impeller and Back Plate is Made of SS (Stainless Steel 316)
● Shaft – SS 316
● Max Head – Upto 28 Meter
● Max Flow – 160 Leter per Minute
● Standard Duty – 6 m3/hr @ 18 Meter
● Inlet & Outlet – 25 mm x 25 mm (Threaded and Flange end Connection)
● Motor Specification – 1 HP, NFPL, 2800 RPM, 50 Hz, 1 Phase / 3 Phase.
● Fluid Temprature – 90° C (Max)
● Seal Type – Single Spring with Ceramic v/s Carbon Facings
● Impeller – Closed Type

Pump Model No: SSM-1.5

● Pump Type – Centrifugal, Horizontal, Monoblock type, Non Self Priming Pump,
● Pump Material – Casing, Impeller and Back Plate is Made of SS (Stainless Steel 316)
● Shaft – SS 316
● Max Head – Upto 28 Meter
● Max Flow – 175 Leter per Minute
● Standard Duty – 8 m3/hr @ 7 Meter
● Inlet & Outlet – 40 mm x 40 mm (Threaded and Flange end Connection)
● Motor Specification – 1.5 HP, NFPL, 2800 RPM, 50 Hz, 1 Phase / 3 Phase.
● Fluid Temprature – 90° C (Max)
● Seal Type – Single Spring with Ceramic v/s Carbon Facings
● Impeller – Closed Type

Pump Model No: SSM-2

● Pump Type – Centrifugal, Horizontal, Monoblock type, Non Self Priming Pump,
● Pump Material – Casing, Impeller and Back Plate is Made of SS (Stainless Steel 316)
● Shaft – SS 316
● Max Head – Upto 32 Meter
● Max Flow – 230 Leter per Minute
● Standard Duty – 8 m3/hr @ 7 Meter
● Inlet & Outlet – 50 mm x 40 mm (Threaded and Flange end Connection)
● Motor Specification – 2 HP, NFPL, 2800 RPM, 50 Hz, 1 Phase / 3 Phase.
● Fluid Temprature – 90° C (Max)
● Seal Type – Single Spring with Ceramic v/s Carbon Facings
● Impeller – Closed Type

Pump Model No: SSM-3

● Motor Specification – 3 HP, NFPL, 2800 RPM, 50 Hz, 1 Phase / 3 Phase.
● Fluid Temprature – 90° C (Max)
● Seal Type – Single Spring with Ceramic v/s Carbon Facings
● Impeller – Closed Type

Pump Model No: SSM-5

● Pump Type – Centrifugal, Horizontal, Monoblock type, Non Self Priming Pump,
● Pump Material – Casing, Impeller and Back Plate is Made of SS (Stainless Steel 316)
● Shaft – SS 316
● Max Head – Upto 54 Meter
● Max Flow – 400 Leter per Minute
● Standard Duty – 8 m3/hr @ 7 Meter
● Inlet & Outlet – 50 mm x 40 mm (Flange end Connection)
● Motor Specification – 5 HP, NFPL, 2800 RPM, 50 Hz, 1 Phase / 3 Phase.
● Fluid Temprature – 90° C (Max)
● Seal Type – Single Spring with Ceramic v/s Carbon Facings
● Impeller – Closed Type

Pump Model No: SSM-7

● Pump Type – Centrifugal, Horizontal, Monoblock type, Non Self Priming Pump,
● Pump Material – Casing, Impeller and Back Plate is Made of SS (Stainless Steel 316)
● Shaft – SS 316
● Max Head – Upto 56 Meter
● Max Flow – 600 Leter per Minute
● Standard Duty – 8 m3/hr @ 7 Meter
● Inlet & Outlet – 50 mm x 40 mm (Flange end Connection)
● Motor Specification – 7.5 HP, NFPL, 2800 RPM, 50 Hz, 1 Phase / 3 Phase.
● Fluid Temprature – 90° C (Max)
● Seal Type – Single Spring with Ceramic v/s Carbon Facings
● Impeller – Closed Type

SS 316 Monoblock Pumps

The Numatic SS Monoblock Pumps Series is a single impeller Closed Coupled Centrifugal Pump made in 316 Stainless Steel making it the right Pump for moving water and aggressive liquids in a vast number of applications where high Chemical resistance is needed. Pump and Impellers made in Stainless Steel 316 with choice of Mechanical Shaft Seals / Motor options in Normal and FLP types makes the Numatic SS316 Monoblock Pumps the right solution for 1000’s of liquids.

SS Monoblock Pump Specifications:

Delivery: up to 51 m³/h
Head: up to 45 m
Power supply: three-phase 50 and 60 Hz
Power: from 0,25 HP up to 10 HP
Temperature of pumped liquid: from -10°C to +100°C

SS Monoblock Pumps | Numatic Pumps

SS Monoblock pumps, also known as stainless steel monoblock pumps, are a type of centrifugal pump used for a variety of applications, including water transfer, irrigation, and industrial processes. They are constructed from stainless steel, making them highly resistant to corrosion and ensuring a long lifespan. In this article, we will discuss the features, benefits, and applications of SS Monoblock pumps.

Features of SS Monoblock Pumps:

Stainless Steel Construction: The use of stainless steel in the construction of SS Monoblock pumps makes them highly resistant to corrosion, rust, and erosion, ensuring durability and longevity.

Compact Design: SS Monoblock pumps have a compact design, making them ideal for use in applications where space is limited.

Single Piece Design: The monoblock design of these pumps means that the motor and pump are combined into a single unit, which simplifies installation and maintenance.

High-Quality Mechanical Seal: SS Monoblock pumps come equipped with high-quality mechanical seals, which provide excellent sealing and prevent leaks.

Self-Priming: Some SS Monoblock pumps are self-priming, which means that they can draw water from a source without requiring a separate priming mechanism.

Benefits of SS Monoblock Pumps

High Efficiency: SS Monoblock pumps are highly efficient, providing excellent performance and energy savings.

Low Maintenance: The single-piece design of SS Monoblock pumps means that they require less maintenance than traditional pumps, reducing downtime and repair costs.

Versatility: SS Monoblock pumps are versatile and can be used in a wide range of applications, including residential, commercial, and industrial.

Durability: The stainless steel construction of SS Monoblock pumps ensures durability and a long lifespan.

Corrosion Resistance: The use of stainless steel in the construction of these pumps makes them highly resistant to corrosion, ensuring reliability and longevity.

Applications of SS Monoblock Pumps

Residential Water Supply: SS Monoblock pumps are commonly used in residential applications such as water supply, irrigation, and gardening.

Commercial Water Supply: SS Monoblock pumps are used in commercial applications such as water supply for buildings, hotels, and resorts.

Industrial Applications: SS Monoblock pumps are used in industrial applications such as chemical and petrochemical processing, pharmaceutical production, and food and beverage processing.

Agriculture: SS Monoblock pumps are used in agriculture for irrigation, water supply, and fertilization.

Marine Applications: The corrosion-resistant properties of SS Monoblock pumps make them suitable for marine applications such as shipbuilding and offshore drilling.

In conclusion, SS Monoblock pumps are versatile, efficient, and reliable pumps suitable for a wide range of applications. The stainless steel construction of these pumps makes them highly resistant to corrosion, ensuring durability and longevity. With their compact design, low maintenance requirements, and high efficiency, SS Monoblock pumps are an excellent investment for any application requiring reliable and efficient pumping.

Stainless Steel Monoblock Pump
We are Leading Manufacturers, Suppliers & Exporters of Stainless Steel 316 Monoblock Pumps In India (Mumbai) for Industries like Pharmaceutical, Food Processing, Beverage, and Dairy etc. The Sanitary Fitting and Construction Form High Grade – Pressed SS 316 ensures smooth and even transfer of liquids. Sturdy construction, easy to install, dismantle and assemble. Highly lapped and finished Mechanical Sealing System ensures leak-proof working.
Our Stainless Steel Monoblock Horizontal Pumps are optimum for pharmaceutical industries. The liquid does not react with the metals or inside the environment of the pump, which ensures the safety of medicines. These are very easy to install. Our Pharmaceutical pumps can be used for as Antibiotics, Streptomycin, Cough Syrup, Health Tonic, Pill Paste, Syrups and Extract, Vitamin Malt Fish Oil and Emulsions. These SS316 Pumps are specially designed and developed as per international industrial standards and find their wide uses in pharmaceutical companies. These are manufactured from optimum quality metals, which ensure its high resistance against various liquids and ensure safe usage. These are widely used for Antibiotics, Health Tonic, Pill Paste, Syrups and Extract, Cough Syrup, Vitamin Malt Fish Oil, Streptomycin and Emulsions.

“Monoblock Centrifugal Stainless Steel Pump”
SSM Model are Stainless Steel Monoblock Centrifugal Pump having Material of construction as Impeller, Shaft, Casing and Stuffing box as SS316 Material. These pumps are widely used in Pharmaceutical Industry, Food Processing Industry, Chemical Industry, Demineralizing Plants, etc.
Stainless Steel Monoblock Centrifugal Pump Motor is designed to perform optimally during low voltage fluctuation due to the ability to adapt to a wide input voltage range of 120 to 220 volts. All wetted parts are SS316 Hygiene Material providing 5 times more protection from Corrosion and Scaling.

Features:
As all pumps are made from rolled Stainless Steel, Mechanical properties are far superior then cast material.
Super finish surface also ensure no ingress or emission of germs or impurities
The pump can handle liquids having viscosities up to 1500 centipoise
Pumps are available with closed / semi-open impellers.
The best elastomers are used in the pumps to provide optimum resistance for high temperatures and chemicals.
Dynamically combinations of the seal faces as per customer’s requirement (single seal / double seal, seal external cooling)
Also available in Flameproof Motors
Various types of connection like – Tri’Clove joints SMS, Flanges or Threaded Nipple / Coupling

Useful information on SS Monoblock Pumps

SS Monoblock pumps are a type of centrifugal pump that are becoming increasingly popular in various industries due to their durability, reliability, and efficiency. Here are some useful pieces of information about SS Monoblock pumps:

Material: As mentioned, SS Monoblock pumps are constructed from stainless steel, which makes them highly resistant to corrosion and erosion. Stainless steel is an alloy that contains at least 10.5% chromium, which gives it its corrosion-resistant properties. Other elements that can be present in stainless steel include nickel, molybdenum, and titanium, depending on the desired properties.

Design: SS Monoblock pumps have a single-piece design, which means that the motor and pump are combined into a single unit. This simplifies installation and maintenance, as there are fewer parts to deal with.

Operation: SS Monoblock pumps operate by using a centrifugal force to move water or other fluids. The impeller rotates, creating a low-pressure area that draws fluid into the pump, and then pushes it out at a higher pressure through the discharge port.

Self-Priming: Some SS Monoblock pumps are self-priming, which means that they can draw water from a source without requiring a separate priming mechanism. This is useful in applications where the pump is located above the water source.

Capacity: SS Monoblock pumps come in a range of capacities, depending on the specific application. The capacity of a pump is measured in terms of flow rate, which is the amount of fluid that can be moved in a given amount of time. The flow rate is typically measured in liters per minute (LPM) or cubic meters per hour (m3/h).

Power: The power of a pump is measured in terms of horsepower (HP) or kilowatts (kW). The power required for a specific application depends on factors such as the flow rate, the head (the vertical distance that the fluid needs to be lifted), and the efficiency of the pump.

Maintenance: SS Monoblock pumps require minimal maintenance, thanks to their single-piece design and high-quality mechanical seals. Regular inspections and cleaning can help ensure optimal performance and longevity.

Cost: SS Monoblock pumps are generally more expensive than traditional pumps due to their stainless steel construction and higher efficiency. However, the long lifespan and low maintenance requirements of these pumps can make them a cost-effective choice in the long run.

Applications: SS Monoblock pumps are suitable for a wide range of applications, including residential and commercial water supply, irrigation, agriculture, and industrial processes such as chemical and petrochemical processing, pharmaceutical production, and food and beverage processing.

In summary, SS Monoblock pumps are a reliable, efficient, and durable choice for a variety of applications. Their stainless steel construction and single-piece design make them highly resistant to corrosion and erosion, while their high-quality mechanical seals ensure excellent sealing and prevent leaks. SS Monoblock pumps are an excellent investment for any application requiring reliable and efficient pumping.

SS Monoblock Pumps? What are they used for?

SS Monoblock pumps are used for a wide range of applications across various industries. Their durability, reliability, and efficiency make them a popular choice for pumping water and other fluids in residential, commercial, and industrial settings. Some of the common applications of SS Monoblock pumps include:

Water supply: SS Monoblock pumps are commonly used for water supply in residential and commercial buildings, such as apartments, hotels, and hospitals. They are used to pump water from wells, boreholes, or municipal water supplies into storage tanks or directly into the building’s plumbing system.

Irrigation: SS Monoblock pumps are used for agricultural irrigation, where they are used to pump water from rivers, ponds, or wells into irrigation systems that distribute water to crops.

Industrial processes: SS Monoblock pumps are used in various industrial processes such as chemical and petrochemical processing, pharmaceutical production, and food and beverage processing. They are used for pumping chemicals, solvents, and other fluids that are involved in the manufacturing process.

Water treatment: SS Monoblock pumps are used in water treatment plants for pumping water from one stage of the treatment process to another. They are used for processes such as sedimentation, filtration, and disinfection.

HVAC systems: SS Monoblock pumps are used in heating, ventilation, and air conditioning (HVAC) systems to circulate water through the system for heating or cooling.

Firefighting: SS Monoblock pumps are used in fire hydrant systems to pump water from the water supply to the firefighting system.

Overall, SS Monoblock pumps are versatile and can be used for a wide range of applications that require reliable and efficient pumping of water or other fluids.
