SS Pneumatic Barrel Pump - SSPB-120

SS316 Pneumatic Barrel Pumps
  • Suction Tube and Impeller – Stainless Steel 316
  • Shaft – Stainless Steel 316
  • Air Motor Capacity – 26000 RPM
  • Air Pressure Required – 6 KG Bar
  • Max Flow – 120 Liter Per Minute
  • Shut of Head – 10 Meter
  • Pump Length – 1000 mm
  • Air Inlet Size – 3/8” Nozzle
  • Inlet & Outlet – Discharge 25mm & Suction 44mm
  • Suitable for – 200 – 210 Ltr Barrel / 50 Ltrs cans
  • Max Viscosity can Operate – 750 CPS
  • Max Gravity can Operate – 1.8
  • Max Temperature – 100° C
  • Suitable Media – Solvents, Acetone, Methanol, Diesel, Sorbitol, Glycerine, Propylene Glycol, Pharmaceuticals ETC.

Price: ₹ 27,000


1) All Prices are Excluding GST.
2) Transportation will be on To pay Basis.

SS Pneumatic Barrel Pump SSPB-120

We manufacture a wide range of Air Operated SS316 Drum Pump. Our range of Air Operated Barrel Pump comprises of Air Operated SS316 Drum Pump, Air Operated SS316 Barrel Pump, etc. Particularly designed in two Capacity 100 LPM 10 Meter Head, 120 LPM 12 Meter Head. The most important feature of these Air Operated Barrel Pumps is its specially developed unit, the unique pump tube, and the axial vane impeller. The power on/off switch is located at the top, for easy functionality. The pump is developed in such a way that it can be easily interchanged and can be easily connected or disconnected to the motor by means of grip collar nut.
To provide high durability chemical resistant anti-corrosive parts like Teflon, Hastelloy C, PP, PVDF, Viton, SS316 are also available. For transferring Solvents, Acids, Alkalis, Petroleum products, etc. Our highly effective Air Operated Impeller Barrel Pump is mostly used in Chemical, Power, Food, Textile, Pharma, Paints Industries, Medical, and heavy Engineering Sectors.

  • Self Priming
  • Stainless Steel, PP, PTFE, Teflon Body
  • Continuous Duty Rated
  • Seal-less
  • Quick Draining
  • High RPM Power
  • Special Air Motor for Speed and Safety
